Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool

Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool

About This Thermostat

MFG: Braeburn
MFG#: 5000
Our#: 172311
Programmable: Yes (5+2)
Stages: 1H & 1C
System Compatibility: Single Stage
Power Options: Battery
Heat/Cool Changeover: Manual
Programmable Fan: Yes
Temperature Limits: No
Keypad Lockout: Yes
Backlight: Yes
Vacation Hold: Yes

Braeburn Model 5000 Digital Programmable Thermostat  - 1 Heat / 1 Cool

FEATURES:

. 5-2 Day Separate Weekday / Weekend Programming
. Large Display with Bright Blue Backlight
. Battery Powered with Latching Relay Output
. Non-Volatile Memory to Maintain User Settings
. Recirculating Fan Mode
. Residual Cooling Fan Delay
. Filter Check Monitor
. Adaptive Recovery Mode (ARMT)
. Adjustable Temperature Differential
. ESD GuardT Electronic Circuitry
. Compressor Short Cycle Protection
. Separate Heating and Cooling Set Point Program Times and Temperatures
. Temporary Program Override for 4 Hours or Until Next Set Point
. Programmable Extended Hold Mode
. Front Access Reset Button
. F° / C° Switch
. Gas / Electric Fan Switch
. Mounts to Vertical or Horizontal Box
. Easy Access Front Battery Door
. Separate O & B Terminals
. Keypad Lockout
. Meets ENERGY STARŪ and California Title 24 Guidelines

SPECIFICATIONS:

Dimensions: 4.63" x 5.00" x 1.25"
Electric Rating: 24 Volt AC (18-30 Volt AC)
1 amp maximum load per terminal
2 amp total maximum load (all terminals)
DC Power: 3.0 Volts DC
(2 "AA" Alkaline batteries included)
Compatibility: Single stage gas, oil or electric systems
Single stage heat pump systems
250mv - 750mv millivolt heating systems
Control Range: 45° to 90° F (7° to 32° C)
Display Range: 40° to 99° F (4° to 37° C)
Accuracy: +/- 1° F (+/- .5° C)
Temperature
Differential: .5°, 1°, or 2° F (.25°, .5°, or 1° C)
Storage Temperature: 14° to 140° F (-10° to 60° C)
Operating Humidity: 5% to 95% Relative Humidity
Interchangeable
Sub-Base: Braeburn 3000 Non-Programmable and
5050 Programmable 1 Heat / 1 Cool
Terminations: Rc, Rh, G, W, Y, B, O

REVIEW SNAPSHOT®

by PowerReviews
Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool

4.5

(based on 19 reviews)

100%

of respondents would recommend this to a friend.

Pros

  • Easy to adjust (17)
  • Easy to install (16)
  • Simple controls (12)
  • Intuitive controls (11)

Cons

    Best Uses

    • Home (17)
    • Central controls (5)
    • Large rooms (5)
      • Reviewer Profile:
      • Homeowner (19), Avid do-it-yourselfer (7)

    Reviewed by 19 customers

    Sort by

    Displaying reviews 1-10

    Back to top

    Previous | Next »


    4.0

    Excellent value

    By Al

    from Omaha, NE

    About Me Handyman, Homeowner

    Verified Buyer

    Pros

    • Easy To Adjust
    • Easy To Install
    • Intuitive Controls
    • Precise Controls

    Cons

    • Recirc not programmable

    Best Uses

      Comments about Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool:

      My house is well insulated but I had a problem with hotspots/coldspots in my house due to the heat/AC not needing to running that often. I wanted a way to run the fan occasionally... the recirculation feature on this thermostat gives me that. I'm happy so far.

      Only minor complaint is that I would prefer that I could adjust the times that the fan cycles on/off when using the recirc feature.


      5.0

      Great Thermostat, Easy to program /Use

      By Speaker Guy

      from Atlanta, GA

      About Me Handyman, Homeowner

      Verified Buyer

      Pros

      • Easy To Adjust
      • Easy To Install
      • Intuitive Controls
      • Precise Controls

      Cons

        Best Uses

        • Central Controls
        • Homes

        Comments about Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool:

        This is a great thermostat. It is easy to program or change programming on an entire week in minutes. Installation instructions well thought out, very intuitive. Has an easy to set/unset HOLD function. Several installation functions are on dip switches... easy to do and clearly explained. This was the only Tstat I found under $120 with a 35% random fan circulation mode which is very helpful in "shoulder" fall and spring to move the air comfortably. Also, the temperature drop differential before the Tstat calls for heat/cool can be varied from .5 deg to 2 degrees. The factory .5 degree holds it close, though maybe not as close as the Honeywell it replaced.


        5.0

        Excellent

        By SpecExec

        from Scottsdale, AZ

        About Me Homeowner

        Verified Buyer

        Pros

        • Easy To Adjust
        • Easy To Install
        • Precise Controls

        Cons

          Best Uses

          • Homes

          Comments about Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool:

          Needed to replace a non-programmable with a programmable thermostat. This item did the trick. Turns out that finding Braeburn thermostats is not that easy at the standard stores ([...]). Prothermostats.com had the item, [...] Very happy....

          (2 of 2 customers found this review helpful)


          4.0

          good features but some gremlins

          By Jack

          from Montville, NJ

          About Me Homeowner

          Verified Buyer

          Pros

            Cons

              Best Uses

              • Homes

              Comments about Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool:

              A lot of useful features.
              However, a times the fan does not stops until I remove the batteries and reset the thermostat

              (1 of 1 customers found this review helpful)


              4.0

              Works fine

              By Rick C

              from Prescott, AZ

              About Me Homeowner

              Verified Buyer

              Pros

              • Easy To Adjust
              • Easy To Install

              Cons

              • Hard To Read Display

              Best Uses

              • Homes

              Comments about Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool:

              Thermostat is easy to install and fits existing screw holes from previous thermostat. I selected it for the recirculating fan cycle which works fine. The characters on the display during programming were not always easily interpreted, e.g. "LG" looks like "L6" and I still don't know what "OC" means, although the manual has an adequate explanation ofwhat it refers to. The normal display is clear.

              (1 of 1 customers found this review helpful)


              4.0

              I would buy this product again and again

              By Bj

              from Atlanta, GA

              About Me Homeowner

              Verified Buyer

              Pros

              • Easy To Adjust
              • Easy To Install

              Cons

              • Temperature Doesn't Hold

              Best Uses

              • Homes

              Comments about Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool:

              used this product for 2 years now - good so far - first one went out after one yr. couldn't find builder to replace.


              5.0

              Good value-works great

              By satisfied

              from NC,Fl

              About Me Handyman, Homeowner

              Verified Buyer

              Pros

              • Easy To Adjust
              • Easy To Install
              • Intuitive Controls
              • Precise Controls
              • Recirculation feature

              Cons

              • Set point not displayed

              Best Uses

              • Central Controls
              • Homes
              • Large Rooms
              • Location with uneven load
              • Offices
              • Small Rooms

              Comments about Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool:

              Lowest cost unit with recirc capability and it works.I've installed one on the main floor of a large house and in an ocean front condo with severe variation in load on either end of the unit.Recirc feature balances load and evens temperature without running fan continuously.


              5.0

              Good product at a good price.

              By dj

              from Longview WA

              About Me Homeowner

              Verified Buyer

              Pros

              • Easy To Adjust
              • Easy To Install
              • Intuitive Controls
              • Precise Controls

              Cons

                Best Uses

                • Central Controls
                • Homes

                Comments about Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool:

                I bought this thermastat to replace the Braeburn 3000. It was about a 15 minute install since I did not have to change the backing plate. I like the recirculate function because I don't have a variable speed air handler.


                5.0

                Nice thermostat

                By RS

                from Sussex, WI

                About Me Homeowner

                Verified Buyer

                Pros

                • Easy To Adjust

                Cons

                • None

                Best Uses

                • Homes

                Comments about Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool:

                I bought this thermostat because it had a recirculate feature that I couldn't find on any other brand. This feature turns on the furnace fan at regular intervals (without heat or AC) to recirculate the air in your home. If you have a two story home, it helps to equalize the temperature. If you have a basement rec room, it keeps it from getting musty. After moving to a new home, it became too annoying not to have this feature and I was surprised that Braeburn was the only thermostat that had it.

                (1 of 1 customers found this review helpful)


                5.0

                Great thermostat!

                By Crash

                from Mountain Home, Arkansas

                About Me Handyman, Homeowner

                Verified Buyer

                Pros

                • Easy To Adjust
                • Easy To Install
                • Intuitive Controls
                • Precise Controls

                Cons

                  Best Uses

                  • Homes
                  • Large Rooms

                  Comments about Braeburn Model 5000 Digital Programmable Thermostat - 1 Heat / 1 Cool:

                  We've always had moisture problems in our basement. This thermostat keeps the air moving and that greatly helps with that issue. I wish I had discovered this years ago. Easy to install/program. Haven't discovered any problems after a couple of weeks usage.
