Jackson Systems Never-OFF-StatT Thermostat Model NOS-HC
About This Thermostat
|Stages:||1H & 1C|
|System Compatibility:||Heat Only, Single Stage|
|Power Options:||24 VAC Hardwire|
Click here for Limit-StatT - does not allow for heat call above 73 degrees!
Jackson Systems Never-OFF-StatT Thermostat Model NOS-HC.
A great product for landlords and property managers! property managers should to be aware of the risk of freezing pipes and water damage caused by tenants who turn the thermostat off when vacating or leaving their dwelling for an extended period of time. This problem alone can lead to thousands of dollars in costly maintenance and renovation repairs each year. Now, it can be totally avoided!
The Model NOS-HC, Never-OFF-StatT operates like a conventional manual changeover heating/cooling, digital thermostat. In normal operation, it allows full user control in selecting mode (HEAT/COOL) and fan (ON/AUTO) as well as adjustment of heating and cooling setpoints. However, when the COOL, OFF, HEAT switch is put in the OFF position, the thermostat will energize the heating system whenever the temperature in the space drops below 55° F. This unique feature greatly reduces the risk of freezing pipes and water damage during the heating season when the thermostat is in the off position for extended unoccupied periods.
20 to 30 VAC 50/60 Hz.
0.05 to 1.2 Amps (Load per terminal)
1.5 Amps Maximum Total Load
(All terminals combined)
Setpoint Temperature Range: 45° to 90° F
(7° to 32° C)
Limiter: 55° F (22.5° C) (+/- 2°) (12.7° C) when SYSTEM SWITCH is in OFF position.
Operating Ambient Temperature: 32°F to 105° F
Operating Humidity Range: 0 to 90% RH (non-condensing)
Shipping Temperature Range: -40°F to 150°F
