White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1)
About This Thermostat
| MFG: | White-Rodgers |
| MFG#: | 1F80-0471 |
| Our#: | 110089 |
| Programmable: | Yes (5+2, 5+1+1 or non-programmable) |
| Stages: | 1H & 1C |
| System Compatibility: | Single Stage, Millivolt, Heat Only |
| Power Options: | 24 VAC Hardwire, Battery |
| Heat/Cool Changeover: | Automatic or Manual |
| Programmable Fan: | No |
| Temperature Limits: | No |
| Keypad Lockout: | No |
| Backlight: | Yes |
| Vacation Hold: | No |
The best-selling digital thermostat series now has Blue. 80 Series Blue has a large 4-square-inch, easy-to-view Blue display and enhanced home comfort features. Take all the best features of the 80 Series, add exclusive CoolSavings™, dedicated programmable or non-programmable, longer battery life with exclusive battery power monitor — put it all in a sleek, compact package and you have 80 Series Blue. Tried and true now comes in Blue!
Exclusive 80 Series Blue Features
Large, 4-square-inch Blue display with easy-to-see characters
Configures as manual heat/cool, auto changeover, heat only or cool only
Exclusive Cool Savings™ feature saves energy during peak A/C demand periods
Hydronic 2 or 3 wire applications
Three anticipation settings
Exclusive battery power monitor
Longer battery life
Easy access battery compartment
Wallplate F61-2634 Included
5-year warranty
Programming
Choice of 5/1/1 day programmable,
5/2 day or non-programmable
4 time and 4 temperature settings per program (heat & cool)
Energy savings up to 33%
Patented pre-programmed software simplifies time and temperature programming
Display
Large LCD with improved contrast for easier reading Lighted display for easier low-light viewing
Comfort & Convenience
Permanent program retention during power loss
Indefinite setpoint Hold or programmable timed Hold up to 8 hours
Air filter change indicator
Simple “set-up” menu to activate optional features
Temporary temperature override until next program period
Soft-touch keypad
Maintains room temperature differential within 1°
Display temperature recalibration (+/- 4°)
Dimensions
4.5"W x 3 .5"H x 1.1"D
Electrical Specifications:
Rating
0 to 30 VAC, 50/60 Hz or DC
0.05 to 1.0 Amp (load per terminal)
1.5 Amps maximum load (all terminals combined)
Standard Systems
Single Stage gas, oil, electric
Single Stage heat pump
Millivolt Systems
Thermal Specifications
Setpoint Temperature Range: 45° to 90° F (7° to 32° C)
80 Series Blue Rated
Differential: 0.4° to 1.7° F
with adjustable anticipation
Operating Ambient Temperature:
32° to 105° F (0° to 40° C)
Operating Humidity Range:
90% non-condensing maximum
Shipping Temperature Range:
-4° to 150° F (-20° to 65° C)
Customers most agreed on the following attributes:
from phoenix, az on 8/12/2009Comments about White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1):
great documentation easy to install
from Decatur, Illinois on 4/20/2009Comments about White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1):
I've had a White-Rodgers thermostat for probably 20 years and have always been happy.
Super fast shipping. Well packed.
from Fellsmere, Florida on 2/16/2009Comments about White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1):
This product has worked for us very well in, not only rental units, but our personal home also. We would reccommend this product to everyone!
[1 of 1 customers found this review helpful]
from Santa Cruz.CA on 2/12/2009Comments about White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1):
Excellent, and this company was very helpful in every way. They are great. The only problem I had was the wiring diagram didn't apply to me and
I needed help getting it wired although it was ultimately very simple (I guess too simple). It
may have too many features for some people,
but the defaults are logical and pretty much what you want. For heat only, wire red to "RH" and White to "W", and remove jumper between RH/RC
from Fuquay Varina, NC on 2/9/2009Comments about White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1):
The product was easy to install except for attaching the wires to the thermonstate. Other then this, it has been working for the last two weeks perfectly and I have no other complaints. It was fairly easy to program, just had to glance at the directions momentarily. I did purchase another thermonstate and found the connections were not the same. I was able to return the product and purchase and new and it all went smoothly.
from Dana Point on 12/30/2008Comments about White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1):
good price, great function, and it looks cool too with the blue light always on!
from Bismarck, ND on 12/4/2008Comments about White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1):
Temperatures to the degree, not tenth. No keypad lockout. Great display. Easy to install. Great value.
from Indiana on 11/24/2008Comments about White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1):
It is easy to install and the directions are very clear. The only problem you might have is the cryptic letters in the settings, but once you read the directions it all makes perfect sense and it is VERY simple.The operation is very easy once you set up the 5+1+1 or 5+2 days.I chose this model over the touch screen model because it is not worth another $70 for just a touch screen that does the EXACT same thing. Actually, this model is better than the touch screen as you have 3 gradients for heat cycles where the touch screen only has 2.
[1 of 1 customers found this review helpful]
from Grenada, MS on 7/22/2008Comments about White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1):
It didn't take any time to program or install, after reading the easy to understand instruction sheet that came with the product. Can't wait to see how much lower my electric bill will be! Highly recommend to everyone with the old style controls. Save money by programming one and not cooling or heating when your at work.
[1 of 1 customers found this review helpful]
from SF, CA on 6/13/2008Comments about White-Rodgers 1F80-0471, Single Stage Heat/Cool, Programmable (5+1+1):
The subject line says it all. I put this unit in several homes, and most recently in my own.
