White-Rodgers 1F78H-151 Programmable (5+2) 1 Heat/1 Cool Thermostat, Hardwired

White-Rodgers 1F78H-151 Programmable (5+2) 1 Heat/1 Cool Thermostat, Hardwired

About This Thermostat

MFG: White-Rodgers
MFG#: 1F78H-151
Our#: 101553
Programmable: Yes (5+2)
Stages: 1H & 1C
System Compatibility: Single Stage
Power Options: 24 VAC Hardwire
Heat/Cool Changeover: Manual
Programmable Fan: No
Temperature Limits: No
Keypad Lockout: No
Backlight: Yes
Vacation Hold: No
FEATURES
. Hardwired (24V).
. Fossil fuel or electric heat compatible.
. Large LCD with backlight.
. Selectable Celsius or Fahrenheit temperature display.
. Includes O and B terminals.
. Classic White color.

SPECIFICATIONS
Electrical Rating . . . . . . . . . . . . . . . . . . . . . mV to 30 VAC, NEC Class II, 50/60 Hz or DC
Terminal Load . . . . . . . . . . . . . . . . . . . . . . . 1.0 A per terminal,
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5A maximum all terminals combined
Setpoint Temperature Range . . . . . . . . . . . 45 to 90F (7 to 32C)
Anticipation, Heating . . . . . . . . . . . . . . . . . . Adjustable
Anticipation, Cooling . . . . . . . . . . . . . . . . . . Adjustable
Rated Differential, Heat . . . . . . . . . . . . . . . 0.6 or 1.5F
Rated Differential, Cool . . . . . . . . . . . . . . . . 1.2F
Operating Ambient Temperature Range . . . 32 to 105F (0 to 41C)
Operating Humidity Range . . . . . . . . . . . . . 0-90% RH noncondensing
Shipping Temperature Range . . . . . . . . . . . -4 to +149F (-20 to +65C)
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 33/4"H x 51/8"W x 11/8"D
