White-Rodgers 1F78-151 Programmable (5+2) 1 Heat/1 Cool Thermostat, Battery Powered
White-Rodgers 1F78-151 Programmable (5+2) 1 Heat/1 Cool Thermostat, Battery Powered
About This Thermostat
| MFG: | White-Rodgers |
| MFG#: | 1F78-151 |
| Our#: | 101552 |
| Programmable: | Yes (5+2) |
| Stages: | 1H & 1C |
| System Compatibility: | Single Stage, Millivolt |
| Power Options: | Battery |
| Heat/Cool Changeover: | Manual |
| Programmable Fan: | No |
| Temperature Limits: | No |
| Keypad Lockout: | No |
| Backlight: | Yes |
| Vacation Hold: | No |
FEATURES
. Battery powered for maximum compatibility.
. Fossil fuel or electric heat compatible.
. Large LCD with backlight.
. Selectable Celsius or Fahrenheit temperature display.
. Includes O and B terminals.
. Classic White color.
SPECIFICATIONS
Electrical Rating . . . . . . . . . . . . . . . . . . . . . mV to 30 VAC, NEC Class II, 50/60 Hz or DC
Terminal Load . . . . . . . . . . . . . . . . . . . . . . . 1.0 A per terminal,
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5A maximum all terminals combined
Setpoint Temperature Range . . . . . . . . . . . 45 to 90°F (7 to 32°C)
Anticipation, Heating . . . . . . . . . . . . . . . . . . Adjustable
Anticipation, Cooling . . . . . . . . . . . . . . . . . . Adjustable
Rated Differential, Heat . . . . . . . . . . . . . . . 0.6 or 1.5°F
Rated Differential, Cool . . . . . . . . . . . . . . . . 1.2°F
Operating Ambient Temperature Range . . . 32 to 105°F (0 to 41°C)
Operating Humidity Range . . . . . . . . . . . . . 0-90% RH noncondensing
Shipping Temperature Range . . . . . . . . . . . -4 to +149°F (-20 to +65°C)
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 33/4"H x 51/8"W x 11/8"D
. Battery powered for maximum compatibility.
. Fossil fuel or electric heat compatible.
. Large LCD with backlight.
. Selectable Celsius or Fahrenheit temperature display.
. Includes O and B terminals.
. Classic White color.
SPECIFICATIONS
Electrical Rating . . . . . . . . . . . . . . . . . . . . . mV to 30 VAC, NEC Class II, 50/60 Hz or DC
Terminal Load . . . . . . . . . . . . . . . . . . . . . . . 1.0 A per terminal,
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5A maximum all terminals combined
Setpoint Temperature Range . . . . . . . . . . . 45 to 90°F (7 to 32°C)
Anticipation, Heating . . . . . . . . . . . . . . . . . . Adjustable
Anticipation, Cooling . . . . . . . . . . . . . . . . . . Adjustable
Rated Differential, Heat . . . . . . . . . . . . . . . 0.6 or 1.5°F
Rated Differential, Cool . . . . . . . . . . . . . . . . 1.2°F
Operating Ambient Temperature Range . . . 32 to 105°F (0 to 41°C)
Operating Humidity Range . . . . . . . . . . . . . 0-90% RH noncondensing
Shipping Temperature Range . . . . . . . . . . . -4 to +149°F (-20 to +65°C)
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 33/4"H x 51/8"W x 11/8"D
