White-Rodgers 1F86-0244 Non-Programmable 1 Heat/1 Cool Thermostat, Battery or Hardwired
About This Thermostat
| MFG: | White-Rodgers |
| MFG#: | 1F86-0244 |
| Our#: | 175114 |
| Programmable: | No |
| Stages: | 1H & 1C |
| System Compatibility: | Single Stage, Millivolt |
| Power Options: | 24 VAC Hardwire, Battery |
| Heat/Cool Changeover: | Manual |
| Programmable Fan: | No |
| Temperature Limits: | No |
| Keypad Lockout: | No |
| Backlight: | Yes |
| Vacation Hold: | No |
Replaces 1F86-241 and 1F86-344
Features:
Display
- Easy-to-read LCD with improved contrast
- Lighted display for easier low-light viewing
Comfort & Convenience
- Permanent program retention during power loss
- Setpoint Hold
- Simple "setup" menu to activate optional features
- Soft-touch keypad
- Display temperature recalibration (+/- 4°)
- Easy access battery compartment
Performance
- Dual-Powered.choice of battery-powered or hardwired, for all applications
- Fast (FA) or slow (SL) heating cycle anticipation
- Easy-to-wire push-connect color coded terminals
- Compressor lockout protection
- Millivolt compatible
- Electric heat option
SPECIFICATIONS
Electrical Rating:
Dual Power or Battery Power Model . . . . mV to 30 VAC, NEC Class II, 50/60 Hz or DC
Input-Hardwire Model . . . . . . . . . . . . . . . . 20 to 30 VAC
Terminal Load . . . . . . . . . . . . . . . . . . . . . . . 1.0 A per terminal,
1.5A maximum all terminals combined
Setpoint Temperature Range . . . . . . . . . . . 45 to 90°F (7 to 32°C)
Anticipation, Heating . . . . . . . . . . . . . . . . . . Adjustable
Anticipation, Cooling . . . . . . . . . . . . . . . . . . Fixed
Rated Differential, Heat . . . . . . . . . . . . . . . 0.6° or 1.2°F
Rated Differential, Cool . . . . . . . . . . . . . . . . 1.2°F
Operating Ambient Temperature Range . . . 32 to 105°F (0 to 44°C)
Operating Humidity Range . . . . . . . . . . . . . 0-90% RH noncondensing
Shipping Temperature Range . . . . . . . . . . . -40 to +150°F (-40 to +65°C)
Dimensions . . . . . . . . . . . . . . . . . . 3-3/4"H x 4-3/4"W x 1-1/2"D
Terminals: R, C, Y, W, G, O/B
