White-Rodgers 1F80-0224 Programmable (24 hours) 1 Heat/1 Cool Thermostat

White-Rodgers 1F80-0224 Programmable (24 hours) 1 Heat/1 Cool Thermostat

About This Thermostat

MFG: White-Rodgers
MFG#: 1F80-0224
Our#: 175103
Programmable: Yes (24 hr)
Stages: 1H & 1C
System Compatibility: Single Stage, Millivolt
Power Options: 24 VAC Hardwire or Battery
Heat/Cool Changeover: Manual
Programmable Fan: No
Temperature Limits: No
Keypad Lockout: No
Backlight: Yes
Vacation Hold: No

This White-Rodgers 1F80-0224 24-Hour Digital Thermostat uses the technology of a solid-state microcomputer to provide precise time/temperature control, as well as offer you the flexibility to design heating and cooling programs that fit your needs. Replaces Old Model Number 1F80-224

Features:

Programmable

  • 24-hour programmable mode
  • 4 time and 4 temperature settings per program (heat & cool)
  • Energy savings up to 33%
  • Patented pre-programmed software simplifies time and temperature programming

Display

  • Easy-to-read LCD with improved contrast
  • Lighted display for easier low-light viewing

Comfort & Convenience

  • Permanent program retention during power loss
  • Setpoint Hold
  • Simple "setup" menu to activate optional features
  • Temporary temperature override two-hour minimum or until next program period
  • Soft-touch keypad
  • Display temperature recalibration (+/- 4)
  • Easy access battery compartment

Performance

  • Dual-Powered.choice of battery-powered or hardwired, for all applications
  • Selectable Energy Management Recovery
  • Meets California Building Code, Title 24
  • Fast (FA) or slow (SL) heating cycle anticipation
  • Easy-to-wire push-connect color coded terminals
  • Compressor lockout protection
  • Millivolt compatible
  • Electric heat option

Specifications:

Dimensions: 4.8"W x 3.8"H x 1.5"D
Setpoint Temperature Range: 45 to 90 F (7 to 32 C)
BlueT 2" Series Rated Differential: 0.6 to 1.7 F with adjustable anticipation
Operating Ambient Temperature: 32 to 105 F (0 to 40 C)
Operating Humidity Range: 90% non-condensing maximum
Terminals: R, C, Y, W, G, O/B


ProThermostats.com Price:

$61.10

In Stock

Quantity

Shipping Details
  • Standard: 2-7 Business Days: Free!
Shipping fees listed are for a quantity of (1)
